•Max. 20Mbps transfer rate
•2 independent Motion.NET Master Rings
•Max. 128 Motion.NET slave modules support
•Programmable Digital Input Notify Event
•Easy installation with RJ45 phone jack and LED diagnostic
•Number of Ring:2
•Transmission speed:2.5Mbps, 5Mbps,10Mbps, 20Mbps with automatic data flow control
•Serial interface:half duplex RS-485 with transformer isolation
•Cable type:CAT5 UTP/STP Ethernet cable
•Surge protection:10KV
•Communication distance:Max. 100m
•Communication slave module number:2 Rings with Max.128 (1 Ring with 64 slaves)
General
• PCI Spec. 2.2;supports 32-bit,3.3V/5V DC operation
• Power consumption:+5V DC at 0.5A typical
• Working temperature:0 to 60℃
